Product Details
Place of Origin: China
Brand Name: Parker
Model Number: PV080
Certifiion: CE ISO 9001
Payment & Shipping Terms
Minimum Order Quantity: 2
Price: NIGOTIATION
Packaging Details: standard box
Delivery Time: 15 work days
Payment Terms: T/T
Supply Ability: 1000/month
Usage: |
Oil,Hydraulic Piston Pump |
Appliion: |
Metering,Other |
Structure: |
Piston Pump |
Power: |
Hydraulic |
Pressure: |
High Pressure |
Fuel: |
Hydraulic |
Theory: |
Hydraulic Pumps |
Standard Or Nonstandard: |
Standard |
Color: |
Black Or As You Need |
Material: |
Cast Iron |
Product Name: |
Hydraulic Pumps,Genuine Rexroth Hydraulic Gear Pump |
Warranty: |
1 Year |
Condition: |
100%new |
Feature: |
High Efficiency,Long Life |
Type: |
Hydraulic Pump Rexroth |
Name: |
Rexroth Piston Pump |
Origin: |
China |
Usage: |
Oil,Hydraulic Piston Pump |
Appliion: |
Metering,Other |
Structure: |
Piston Pump |
Power: |
Hydraulic |
Pressure: |
High Pressure |
Fuel: |
Hydraulic |
Theory: |
Hydraulic Pumps |
Standard Or Nonstandard: |
Standard |
Color: |
Black Or As You Need |
Material: |
Cast Iron |
Product Name: |
Hydraulic Pumps,Genuine Rexroth Hydraulic Gear Pump |
Warranty: |
1 Year |
Condition: |
100%new |
Feature: |
High Efficiency,Long Life |
Type: |
Hydraulic Pump Rexroth |
Name: |
Rexroth Piston Pump |
Origin: |
China |
| Model No | Hydraulic Pump Parts for PV032/PV046/PV092/PV140/PV180/PV270 |
| Types | Replacement Parts for Hydraulic Piston Pumps |
| Function | Completely Interchargeable with Original Pump |
| Produce Type | OEM&ODM Accept |
| Universality | International General Standard Parts |
| PV016 | PV020 | PV023 | PV028 | PV032 | PV040 | PV046 | ||
| Frame size | 1 | 1 | 1 | 1 | 2 | 2 | 2 | |
| Max. Displacement | [cm3/rev.] | 16 | 20 | 23 | 28 | 32 | 40 | 46 |
| Output flow at 1500 rpm | [l/min] | 24 | 30 | 34,5 | 42 | 48 | 60 | 69 |
| Nominal pressure pN | [bar] | 350 | 350 | 350 | 350 | 350 | 350 | 350 |
| Min. outlet pressure | [bar] | 15 | 15 | 15 | 15 | 15 | 15 | 15 |
| Max. pressure pmax at 20% working cycle1) | [bar] | 420 | 420 | 420 | 420 | 420 | 420 | 420 |
| drain pressure, continuous | [bar] | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 |
| drain pressure, max. peak | [bar] | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 |
| Min. Inlet pressure, abs. | [bar] | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 |
| Max. Inlet pressure | [bar] | 16 | 16 | 16 | 16 | 16 | 16 | 16 |
| Input power at 1500 rpm and 350 bar | [kW] | 15.5 | 19.5 | 22.5 | 27.5 | 31 | 39 | 45 |
| Max speed at 1 bar, abs, inlet pressure | [rpm] | 3000 | 3000 | 3000 | 3000 | 2800 | 2800 | 2800 |
| Min. speed | [rpm] | 50 | 50 | 50 | 50 | 50 | 50 | 50 |
| Moment of inertia | [kgm2] | 0.0017 | 0.0017 | 0.0017 | 0.0017 | 0.0043 | 0.0043 | 0.0043 |
| Weight | [kg] | 19 | 19 | 19 | 19 | 30 | 30 | 30 |
| PV063 | PV080 | PV092 | PV140 | PV180 | PV270 | PV360 | ||
| Frame size | 3 | 3 | 3 | 4 | 4 | 5 | 6 | |
| Max. Displacement | [cm3/rev.] | 63 | 80 | 92 | 140 | 180 | 270 | 360 |
| Output flow at 1500 rpm | [l/min] | 94.5 | 120 | 138 | 210 | 270 | 405 | 540 |
| Nominal pressure pN | [bar] | 350 | 350 | 350 | 350 | 350 | 350 | 350 |
| Min. outlet pressure | [bar] | 15 | 15 | 15 | 15 | 15 | 15 | 15 |
| Max. pressure pmax at 20% working cycle | [bar] | 420 | 420 | 420 | 420 | 420 | 420 | 420 |
| drain pressure, continuous | [bar] | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 |
| drain pressure, max. peak | [bar] | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 |
| Min. Inlet pressure, abs. | [bar] | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 |
| Max. Inlet pressure | [bar] | 16 | 16 | 16 | 16 | 16 | 16 | 16 |
| Input power at 1500 rpm and 350 bar | [kW] | 61.5 | 78 | 89.5 | 136 | 175 | 263 | 350 |
| Max speed at 1 bar, abs, inlet pressure | [rpm] | 2800 | 2500 | 2300 | 2400 | 2200 | 1800 | 1750 |
| Min. speed | [rpm] | 50 | 50 | 50 | 50 | 50 | 50 | 50 |
| Moment of inertia | [kgm] | 0.018 | 0.018 | 0.018 | 0.030 | 0.030 | 0.098 | 0.103 |
| Weight | [kg] | 59 | 59 | 59 | 90 | 90 | 172 | 180 |
Parker PV series including :
PV016, PV020, PV023, PV040, PV046, PV063, PV071, PV080, PV092, PV140, PV180, PV270 hydraulic parker PV axial piston pump With thru drive for single and multiple pumps Swash plate type for open circuit but all the inner parts are 100% replacement with each types .
| Parker PV063 | PV063L1K1T1NFWS |
| Parker PV063 | PV063L1K1T1NMMC |
| Parker PV063 | PV063R1D1T1VMMC |
| Parker PV063 | PV063R1D3A1N001 |
| Parker PV063 | PV063R1D3T1N001 |
| Parker PV063 | PV063R1E1T1N001 |
| Parker PV063 | PV063R1E1T1NMFC |
| Parker PV063 | PV063R1E8T1NFWS |
| Parker PV063 | PV063R1E8T1NMMC |
| Parker PV063 | PV063R1K1A1NFHS |
| Parker PV063 | PV063R1K1A1VFPR |
| Parker PV063 | PV063R1K1A4NFR1 |
| Parker PV063 | PV063R1K1AYNMRZ |
| Parker PV063 | PV063R1K1B1N100 |
| Parker PV063 | PV063R1K1C1NFWS |
| Parker PV063 | PV063R1K1JHNMMC |
| Parker PV063 | PV063R1K1S1NFWS |
| Parker PV063 | PV063R1K1T1N001 |
| Parker PV063 | PV063R1K1T1N100 |
| Parker PV063 | PV063R1K1T1NFDS |
| Parker PV063 | PV063R1K1T1NFF1 |
| Parker PV063 | PV063R1K1T1NFFC |
| Parker PV063 | PV063R1K1T1NFFP |
| Parker PV063 | PV063R1K1T1NFHS |
| Parker PV063 | PV063R1K1T1NFPR |
| Parker PV063 | PV063R1K1T1NFPV |
| Parker PV063 | PV063R1K1T1NFR1 |
| Parker PV063 | PV063R1K1T1NFRC |
| Parker PV063 | PV063R1K1T1NFRZ |
| Parker PV063 | PV063R1K1T1NFWS |
| Parker PV063 | PV063R1K1T1NGLC |
| Parker PV063 | PV063R1K1T1NHCC |
| Parker PV063 | PV063R1K1T1NHLC |
| Parker PV063 | PV063R1K1T1NKLC |
| Parker PV063 | PV063R1K1T1NMF1 |
| Parker PV063 | PV063R1K1T1NMFC |
| Parker PV063 | PV063R1K1T1NMM1 |
| Parker PV063 | PV063R1K1T1NMMC |
| Parker PV063 | PV063R1K1T1NMMK |
| Parker PV063 | PV063R1K1T1NMR1 |
| Parker PV063 | PV063R1K1T1NMRC |
| Parker PV063 | PV063R1K1T1NMRK |
| Parker PV063 | PV063R1K1T1NMRW |
| Parker PV063 | PV063R1K1T1NMRZ |
| Parker PV063 | PV063R1K1T1NMSZ |
| Parker PV063 | PV063R1K1T1NMTP |
| Parker PV063 | PV063R1K1T1NSC1 |
| Parker PV063 | PV063R1K1T1NSCC |
| Parker PV063 | PV063R1K1T1NSCK |
| Parker PV063 | PV063R1K1T1NSL1 |
| Parker PV063 | PV063R1K1T1NSLA |
| Parker PV063 | PV063R1K1T1NSLB |
| Parker PV063 | PV063R1K1T1NSLC |
| Parker PV063 | PV063R1K1T1NSLZ |
| Parker PV063 | PV063R1K1T1NTC1 |
| Parker PV063 | PV063R1K1T1NTCC |
| Parker PV063 | PV063R1K1T1NTL1 |
| Parker PV063 | PV063R1K1T1NTLA |
| Parker PV063 | PV063R1K1T1NTLB |
| Parker PV063 | PV063R1K1T1NTLC |
| Parker PV063 | PV063R1K1T1NTLZ |
| Parker PV063 | PV063R1K1T1NUCC |
| Parker PV063 | PV063R1K1T1NUL1 |
| Parker PV063 | PV063R1K1T1NUPD |
| Parker PV063 | PV063R1K1T1NUPF |
| Parker PV063 | PV063R1K1T1NUPG |
| Parker PV063 | PV063R1K1T1NUPK |
| Parker PV063 | PV063R1K1T1NUPM |
| Parker PV063 | PV063R1K1T1NUPR |
| Parker PV063 | PV063R1K1T1NUPT |
| Parker PV063 | PV063R1K1T1NWCC |
| Parker PV063 | PV063R1K1T1NWLK |
| Parker PV063 | PV063R1K1T1VFDS |
| Parker PV063 | PV063R1K1T1VFFC |
| Parker PV063 | PV063R1K1T1VFHS |
| Parker PV063 | PV063R1K1T1VFPV |
| Parker PV063 | PV063R1K1T1VFRC |
| Parker PV063 | PV063R1K1T1VFT1 |
| Parker PV063 | PV063R1K1T1VFWS |
| Parker PV063 | PV063R1K1T1VMFC |
| Parker PV063 | PV063R1K1T1VMM1 |
| Parker PV063 | PV063R1K1T1VMMC |
| Parker PV063 | PV063R1K1T1VMR1 |
| Parker PV063 | PV063R1K1T1VMRC |
| Parker PV063 | PV063R1K1T1VUPG |
| Parker PV063 | PV063R1K1T1WFDS |
| Parker PV063 | PV063R1K1T1WFF1 |
| Parker PV063 | PV063R1K1T1WFFP |
| Parker PV063 | PV063R1K1T1WFHS |
| Parker PV063 | PV063R1K1T1WFR1 |
| Parker PV063 | PV063R1K1T1WFWS |
| Parker PV063 | PV063R1K1T1WKLB |
| Parker PV063 | PV063R1K1T1WMFC |
| Parker PV063 | PV063R1K1T1WMFK |
| Parker PV063 | PV063R1K1T1WMM1 |
| Parker PV063 | PV063R1K1T1WMMC |
| Parker PV063 | PV063R1K1T1WMR1 |
| Parker PV063 | PV063R1K1T1WMRC |
| Parker PV063 | PV063R1K1T1WUPD |
| Parker PV063 | PV063R1K1T1WUPG |
| Parker PV063 | PV063R1K1T1WUPR |
| Parker PV063 | PV063R1K4A1NFFC |
| Parker PV063 | PV063R1K4B1NFFP |
| Parker PV063 | PV063R1K4C1NUPR |
| Parker PV063 | PV063R1K4K1NFFC |
| Parker PV063 | PV063R1K4K1NUPG |
| Parker PV063 | PV063R1K4KJNUPF |
| Parker PV063 | PV063R1K4LKNMFC |
| Parker PV063 | PV063R1K4T1NFDS |
| Parker PV063 | PV063R1K4T1NFF1 |
| Parker PV063 | PV063R1K4T1NFFC |
| Parker PV063 | PV063R1K4T1NFFP |
| Parker PV063 | PV063R1K4T1NFHS |
| Parker PV063 | PV063R1K4T1NFPV |
| Parker PV063 | PV063R1K4T1NFR1 |
| Parker PV063 | PV063R1K4T1NFRC |
| Parker PV063 | PV063R1K4T1NGLA |
| Parker PV063 | PV063R1K4T1NGLB |
| Parker PV063 | PV063R1K4T1NGLC |
| Parker PV063 | PV063R1K4T1NHCC |
| Parker PV063 | PV063R1K4T1NMCC |
| Parker PV063 | PV063R1K4T1NMFB |
| Parker PV063 | PV063R1K4T1NMFC |
| Parker PV063 | PV063R1K4T1NMFZ |
| Parker PV063 | PV063R1K4T1NMLC |
| Parker PV063 | PV063R1K4T1NMMC |
| Parker PV063 | PV063R1K4T1NMR1 |
| Parker PV063 | PV063R1K8S1NFWS |
| Parker PV063 | PV063R1K8T1N001 |
| Parker PV063 | PV063R1K8T1NFHS |
| Parker PV063 | PV063R1K8T1NFPV |
| Parker PV063 | PV063R1K8T1NFWS |
| Parker PV063 | PV063R1K8T1NMMC |
| Parker PV063 | PV063R1K8T1NMRC |
| Parker PV063 | PV063R1K8T1NMTP |
| Parker PV063 | PV063R1K8T1NULA |
| Parker PV063 | PV063R1K8T1NUPG |
| Parker PV063 | PV063R1K8T1NUPR |
| Parker PV063 | PV063R1K8T1V001 |
| Parker PV063 | PV063R1K8T1V100 |
| Parker PV063 | PV063R1K8T1VMMC |
| Parker PV063 | PV063R1K8T1WFR1 |
| Parker PV063 | PV063R1L1A4NFPV |
| Parker PV063 | PV063R1L1AYNFPV |
| Parker PV063 | PV063R1L1T1N001 |
| Parker PV063 | PV063R1L1T1N100 |
| Parker PV063 | PV063R1L1T1NFR1 |
| Parker PV063 | PV063R1L1T1NFRC |
| Parker PV063 | PV063R1L1T1NFRP |
| Parker PV063 | PV063R1L1T1NFSD |
| Parker PV063 | PV063R1L1T1NFT1 |
| Parker PV063 | PV063R1L1T1NFWS |
| Parker PV063 | PV063R1L1T1NGL1 |
| Parker PV063 | PV063R1L1T1NHCC |
| Parker PV063 | PV063R1L1T1NHL1 |
| Parker PV063 | PV063R1L1T1NHLC |
| Parker PV063 | PV063R1L1T1NKCC |
| Parker PV063 | PV063R1L1T1NMCC |
| Parker PV063 | PV063R1L1T1NMF1 |
| Parker PV063 | PV063R1L1T1NMFC |
| Parker PV063 | PV063R1L1T1NMFK |
| Parker PV063 | PV063R1L1T1NMM1 |
| Parker PV063 | PV063R1L1T1NMMC |
| Parker PV063 | PV063R1L1T1NMMK |
| Parker PV063 | PV063R1L1T1NMMW |
| Parker PV063 | PV063R1L1T1NMRC |
| Parker PV063 | PV063R1L1T1NSCC |
| Parker PV063 | PV063R1L1T1NUCC |
| Parker PV063 | PV063R1L1T1NUPG |
| Parker PV063 | PV063R1L1T1NUPR |
| Parker PV063 | PV063R1L1T1PUPG |
| Parker PV063 | PV063R1L1T1VFFC |
| Parker PV063 | PV063R1L1T1VMFC |
| Parker PV063 | PV063R1L4T1N001 |
| Parker PV063 | PV063R1L4T1NFF1 |
| Parker PV063 | PV063R1L4T1NFFC |
| Parker PV063 | PV063R1L4T1NFWS |
| Parker PV063 | PV063R1L4T1NMFC |
| Parker PV063 | PV063R1L4T1NMMC |
| Parker PV063 | PV063R1L4T1NMMW |
| Parker PV063 | PV063R1L4T1NUPM |
| Parker PV063 | PV063R1L8T1NFRP |
| Parker PV063 | PV063R2K1T1N001 |
| Parker PV063 | PV063R2L1T1N001 |
| Parker PV063 | PV063R9E1T1NMFC |
| Parker PV063 | PV063R9E1T1NUCC |
| Parker PV063 | PV063R9K1ABNMMW |
| Parker PV063 | PV063R9K1C1NMRC |
| Parker PV063 | PV063R9K1T1NFPV |
| Parker PV063 | PV063R9K1T1NFWS |
| Parker PV063 | PV063R9K1T1NHCC |
| Parker PV063 | PV063R9K1T1NHLC |
| Parker PV063 | PV063R9K1T1NMFB |
| Parker PV063 | PV063R9K1T1NMFC |
| Parker PV063 | PV063R9K1T1NMMC |
| Parker PV063 | PV063R9K1T1VMMC |
| Parker PV063 | PV063R9K1T1WMCC |
| Parker PV063 | PV063R9K4C1NMRC |
| Parker PV063 | PV063R9K4CDNMRC |
| Parker PV063 | PV063R9K4KJNMFC |
| Parker PV063 | PV063R9L1T1NFWS |
| Parker PV063 | PV063R9L1TNMPCK |
| Parker PV080 | PV080L1K1T1N001 |
| Parker PV080 | PV080L1K1T1N100 |
| Parker PV080 | PV080L1K1T1NFFC |
| Parker PV080 | PV080L1K1T1NFHS |
| Parker PV080 | PV080L1K1T1NFWS |
| Parker PV080 | PV080L1K1T1NMMC |
| Parker PV080 | PV080R1D1T1NMMC |
| Parker PV080 | PV080R1D1T1VFWS |
| Parker PV080 | PV080R1D1T1VMMC |
| Parker PV080 | PV080R1D3C1NGLA |
| Parker PV080 | PV080R1D3C1NKLA |
| Parker PV080 | PV080R1D3C1NKLW |
| Parker PV080 | PV080R1D3CDNMMC |
| Parker PV080 | PV080R1D3DFNUPP |
| Parker PV080 | PV080R1D3T1NFDS |
| Parker PV080 | PV080R1D3T1NFHS |
| Parker PV080 | PV080R1D3T1NFWS |
| Parker PV080 | PV080R1D3T1NKLC |
| Parker PV080 | PV080R1D3T1NMCC |
| Parker PV080 | PV080R1D3T1NMF1 |
| Parker PV080 | PV080R1D3T1NMLC |
| Parker PV080 | PV080R1D3T1NMMW |
| Parker PV080 | PV080R1D3T1NUPK |
| Parker PV080 | PV080R1D3T1NUPM |
| Parker PV080 | PV080R1D7T1VMFC |
| Parker PV080 | PV080R1E1AYNUPR |
| Parker PV080 | PV080R1E1BBNMT1 |
| Parker PV080 | PV080R1E8T1NMMC |
| Parker PV080 | PV080R1K1A1NFR1 |
| Parker PV080 | PV080R1K1A1NFWS |
| Parker PV080 | PV080R1K1A1NHLC |
| Parker PV080 | PV080R1K1A1NMMC |
| Parker PV080 | PV080R1K1AYNFRC |
| Parker PV080 | PV080R1K1AYNMRZ |
| Parker PV080 | PV080R1K1AYNUPM |
| Parker PV080 | PV080R1K1AYNUPR |
| Parker PV080 | PV080R1K1B1NSLB |
| Parker PV080 | PV080R1K1JHNMMC |
| Parker PV080 | PV080R1K1S1NFWS |
| Parker PV080 | PV080R1K1T1N001 |
| Parker PV080 | PV080R1K1T1N100 |
| Parker PV080 | PV080R1K1T1NFDS |
| Parker PV080 | PV080R1K1T1NFF1 |
| Parker PV080 | PV080R1K1T1NFFC |
| Parker PV080 | PV080R1K1T1NFFp |
| Parker PV080 | PV080R1K1T1NFHS |
| Parker PV080 | PV080R1K1T1NFPV |
| Parker PV080 | PV080R1K1T1NFR1 |
| Parker PV080 | PV080R1K1T1NFR2 |
| Parker PV080 | PV080R1K1T1NFRC |
| Parker PV080 | PV080R1K1T1NFRD |
| Parker PV080 | PV080R1K1T1NFRL |
| Parker PV080 | PV080R1K1T1NFRP |
| Parker PV080 | PV080R1K1T1NFRZ |
| Parker PV080 | PV080R1K1T1NFT1 |
| Parker PV080 | PV080R1K1T1NFWS |
| Parker PV080 | PV080R1K1T1NGCC |
| Parker PV080 | PV080R1K1T1NGCK |
| Parker PV080 | PV080R1K1T1NGLA |
| Parker PV080 | PV080R1K1T1NGLC |
| Parker PV080 | PV080R1K1T1NHCC |
| Parker PV080 | PV080R1K1T1NHCD |
| Parker PV080 | PV080R1K1T1NHLC |
| Parker PV080 | PV080R1K1T1NKLC |
| Parker PV080 | PV080R1K1T1NMF1 |
| Parker PV080 | PV080R1K1T1NMFC |
| Parker PV080 | PV080R1K1T1NML1 |
| Parker PV080 | PV080R1K1T1NMLC |
| Parker PV080 | PV080R1K1T1NMLZ |
| Parker PV080 | PV080R1K1T1NMM1 |
| Parker PV080 | PV080R1K1T1NMMC |
| Parker PV080 | PV080R1K1T1NMMK |
| Parker PV080 | PV080R1K1T1NMMW |
| Parker PV080 | PV080R1K1T1NMMZ |
| Parker PV080 | PV080R1K1T1NMR1 |
| Parker PV080 | PV080R1K1T1NMRC |
| Parker PV080 | PV080R1K1T1NMRK |
| Parker PV080 | PV080R1K1T1NMRW |
| Parker PV080 | PV080R1K1T1NMRZ |
| Parker PV080 | PV080R1K1T1NMT1 |
| Parker PV080 | PV080R1K1T1NMTP |
| Parker PV080 | PV080R1K1T1NSC1 |
| Parker PV080 | PV080R1K1T1NSCB |
| Parker PV080 | PV080R1K1T1NSCC |
| Parker PV080 | PV080R1K1T1NSL1 |
| Parker PV080 | PV080R1K1T1NSLA |
| Parker PV080 | PV080R1K1T1NSLC |
| Parker PV080 | PV080R1K1T1NSLD |
| Parker PV080 | PV080R1K1T1NSLK |
| Parker PV080 | PV080R1K1T1NSLZ |
| Parker PV080 | PV080R1K1T1NTCC |
| Parker PV080 | PV080R1K1T1NTLC |
| Parker PV080 | PV080R1K1T1NTLD |
| Parker PV080 | PV080R1K1T1NUCC |
| Parker PV080 | PV080R1K1T1NUPE |
| Parker PV080 | PV080R1K1T1NUPG |
| Parker PV080 | PV080R1K1T1NUPR |
| Parker PV080 | PV080R1K1T1NWLC |
| Parker PV080 | PV080R1K1T1VFDS |
| Parker PV080 | PV080R1K1T1VMM1 |
| Parker PV080 | PV080R1K1T1VMMC |
| Parker PV080 | PV080R1K1T1WFDS |
| Parker PV080 | PV080R1K1T1WFR1 |
| Parker PV080 | PV080R1K1T1WMM1 |
| Parker PV080 | PV080R1K1T1WMMC |
| Parker PV080 | PV080R1K1T1WMR1 |
| Parker PV080 | PV080R1K1T1WMRC |
| Parker PV080 | PV080R1K4T1N001 |
| Parker PV080 | PV080R1K4T1NFHS |
| Parker PV080 | PV080R1K4T1NFR1 |
| Parker PV080 | PV080R1K4T1NMM1 |
| Parker PV080 | PV080R1K4T1NMMC |
| Parker PV080 | PV080R1K4T1NMMZ |
| Parker PV080 | PV080R1K4T1NMR1 |
| Parker PV080 | PV080R1K4T1NMRC |
| Parker PV080 | PV080R1K4T1NMT2 |
| Parker PV080 | PV080R1K4T1NSC1 |
| Parker PV080 | PV080R1K4T1NSL1 |
| Parker PV080 | PV080R1K4T1NSLA |
| Parker PV080 | PV080R1K4T1NSLK |
| Parker PV080 | PV080R1K4T1NSLZ |
| Parker PV080 | PV080R1K4T1NTCC |
| Parker PV080 | PV080R1K4T1NUPG |
| Parker PV080 | PV080R1K4T1NUPM |
| Parker PV080 | PV080R1K4T1NUPR |
| Parker PV080 | PV080R1K4T1VFHS |
| Parker PV080 | PV080R1K8T1N001 |
| Parker PV080 | PV080R1K8T1NFPV |
| Parker PV080 | PV080R1K8T1NFWS |
| Parker PV080 | PV080R1K8T1NMMC |
| Parker PV080 | PV080R1K8T1VMMC |
| Parker PV080 | PV080R1L1B4NTCB |
| Parker PV080 | PV080R1L1J1NFFP |
| Parker PV080 | PV080R1L1KJNUCC |
| Parker PV080 | PV080R1L1L1NUPG |
| Parker PV080 | PV080R1L1L3NTCB |
| Parker PV080 | PV080R1L1LKNMMC |
| Parker PV080 | PV080R1L1LKNSCB |
| Parker PV080 | PV080R1L1LKNTCC |
| Parker PV080 | PV080R1L1LKNUCC |
| Parker PV080 | PV080R1L1LKWFPV |
| Parker PV080 | PV080R1L1T1MULC |
| Parker PV080 | PV080R1L1T1N001 |
| Parker PV080 | PV080R1L1T1N100 |
| Parker PV080 | PV080R1L1T1NFDS |
| Parker PV080 | PV080R1L1T1NFFC |
| Parker PV080 | PV080R1L1T1NFFP |
| Parker PV080 | PV080R1L1T1NFHS |
| Parker PV080 | PV080R1L1T1NFPV |
| Parker PV080 | PV080R1L1T1NFR1 |
| Parker PV080 | PV080R1L1T1NFR2 |
| Parker PV080 | PV080R1L1T1NFRC |
| Parker PV080 | PV080R1L1T1NFT1 |
| Parker PV080 | PV080R1L1T1NFWS |
| Parker PV080 | PV080R1L1T1NKLC |
| Parker PV080 | PV080R1L1T1NMF1 |
| Parker PV080 | PV080R1L1T1NMFC |
| Parker PV080 | PV080R1L1T1NMLA |
| Parker PV080 | PV080R1L1T1NMLC |
| Parker PV080 | PV080R1L1T1NMMC |
| Parker PV080 | PV080R1L1T1NMMK |
| Parker PV080 | PV080R1L1T1NMMW |
| Parker PV080 | PV080R1L1T1NMRC |
| Parker PV080 | PV080R1L1T1NSCB |
| Parker PV080 | PV080R1L1T1NSL1 |
| Parker PV080 | PV080R1L1T1NTCC |
| Parker PV080 | PV080R1L1T1NUCC |
| Parker PV080 | PV080R1L1T1NULA |
| Parker PV080 | PV080R1L1T1NUPE |
| Parker PV080 | PV080R1L1T1NUPG |
| Parker PV080 | PV080R1L1T1NUPM |
| Parker PV080 | PV080R1L1T1NUPR |
| Parker PV080 | PV080R1L1T1NWLC |
| Parker PV080 | PV080R1L1T1VFDS |
| Parker PV080 | PV080R1L1T1VMR1 |
| Parker PV080 | PV080R1L1T1WTCC |
| Parker PV080 | PV080R1L4BBNMMC |
| Parker PV080 | PV080R1L4CDNUPM |
| Parker PV080 | PV080R1L4T1NFWS |
| Parker PV080 | PV080R1L4T1NMFC |
| Parker PV080 | PV080R1L4T1NSCZ |
| Parker PV080 | PV080R1L4T1NUPG |
| Parker PV080 | PV080R1L4T1NUPM |
| Parker PV080 | PV080R1L4T1VFWS |
| Parker PV080 | PV080R1L4T1VMMC |
| Parker PV080 | PV080R1L4T1WFWS |
| Parker PV080 | PV080R1L8L3NULC |
| Parker PV080 | PV080R1L8T1NFHS |
| Parker PV080 | PV080R2K1T1N001 |
| Parker PV080 | PV080R2L1T1WMMW |
| Parker PV080 | PV080R2L4T1WMMW |
| Parker PV080 | PV080R9E1BBNMT1 |
| Parker PV080 | PV080R9E1BBWMT2 |
| Parker PV080 | PV080R9E1DFWMT2 |
| Parker PV080 | PV080R9K1AYNGLB |
| Parker PV080 | PV080R9K1BBN100 |
| Parker PV080 | PV080R9K1T1NFWS |
| Parker PV080 | PV080R9K1T1NMFC |
| Parker PV080 | PV080R9K1T1NMM1 |
| Parker PV080 | PV080R9K1T1NMMC |
| Parker PV080 | PV080R9K1T1NMRC |
| Parker PV080 | PV080R9K1T1NSC1 |
| Parker PV080 | PV080R9K1T1NTCC |
| Parker PV080 | PV080R9K1T1NUCC |
| Parker PV080 | PV080R9L1T1NMFC |
| Parker PV080 | PV080R9L1T1NMMC |
| Parker PV092 | PV092L1D3T1N001 |
| Parker PV092 | PV092L1D3T1V001 |
| Parker PV092 | PV092L1E7T1NFPR |
| Parker PV092 | PV092L1K1J1NFR1 |
| Parker PV092 | PV092L1K1T1N001 |
| Parker PV092 | PV092L1K1T1NFHS |
| Parker PV092 | PV092L1K1T1NFWS |
| Parker PV092 | PV092L1K1T1NMMC |
| Parker PV092 | PV092L2E1T1N001 |
| Parker PV092 | PV092L2L1T1N001 |
| Parker PV092 | PV092R1D1T1N001 |
| Parker PV092 | PV092R1D1T1NGLC |
| Parker PV092 | PV092R1D1T1NMMC |
| Parker PV092 | PV092R1D1T1VMMC |
| Parker PV092 | PV092R1D3T1N001 |
| Parker PV092 | PV092R1D3T1V001 |
| Parker PV092 | PV092R1E1T1N001 |
| Parker PV092 | PV092R1E8AYNWLC |
| Parker PV092 | PV092R1E8DFNWLC |
| Parker PV092 | PV092R1K1A1N001 |
| Parker PV092 | PV092R1K1A1NFWS |
| Parker PV092 | PV092R1K1A1NMMC |
| Parker PV092 | PV092R1K1A1NSLA |
| Parker PV092 | PV092R1K1A4WFRZ |
| Parker PV092 | PV092R1K1AYNMRZ |
| Parker PV092 | PV092R1K1JHNMMC |
| Parker PV092 | PV092R1K1K1NFPR |
| Parker PV092 | PV092R1K1K1NTCB |
| Parker PV092 | PV092R1K1K1VFTD |
| Parker PV092 | PV092R1K1KJNSCW |
| Parker PV092 | PV092R1K1L1NFPD |
| Parker PV092 | PV092R1K1L1NGLC |
| Parker PV092 | PV092R1K1L1VFTD |
| Parker PV092 | PV092R1K1L1WFPD |
| Parker PV092 | PV092R1K1L3NHCC |
| Parker PV092 | PV092R1K1LKNFPV |
| Parker PV092 | PV092R1K1S1NFWS |
| Parker PV092 | PV092R1K1T1EMMC |
| Parker PV092 | PV092R1K1T1N001 |
| Parker PV092 | PV092R1K1T1N100 |
| Parker PV092 | PV092R1K1T1NFDS |
| Parker PV092 | PV092R1K1T1NFF1 |
| Parker PV092 | PV092R1K1T1NFFC |
| Parker PV092 | PV092R1K1T1NFFP |
| Parker PV092 | PV092R1K1T1NFHS |
| Parker PV092 | PV092R1K1T1NFPD |
| Parker PV092 | PV092R1K1T1NFPE |
| Parker PV092 | PV092R1K1T1NFPG |
| Parker PV092 | PV092R1K1T1NFPP |
| Parker PV092 | PV092R1K1T1NFPR |
| Parker PV092 | PV092R1K1T1NFPS |
| Parker PV092 | PV092R1K1T1NFPV |
| Parker PV092 | PV092R1K1T1NFR1 |
| Parker PV092 | PV092R1K1T1NFRC |
| Parker PV092 | PV092R1K1T1NFRZ |
| Parker PV092 | PV092R1K1T1NFS1 |
| Parker PV092 | PV092R1K1T1NFSP |
| Parker PV092 | PV092R1K1T1NFT1 |
| Parker PV092 | PV092R1K1T1NFTP |
| Parker PV092 | PV092R1K1T1NFWS |
| Parker PV092 | PV092R1K1T1NGCA |
| Parker PV092 | PV092R1K1T1NGCC |
| Parker PV092 | PV092R1K1T1NGCD |
| Parker PV092 | PV092R1K1T1NGL1 |
| Parker PV092 | PV092R1K1T1NGLA |
| Parker PV092 | PV092R1K1T1NGLC |
| Parker PV092 | PV092R1K1T1NGLW |
| Parker PV092 | PV092R1K1T1NHCB |
| Parker PV092 | PV092R1K1T1NHCC |
| Parker PV092 | PV092R1K1T1NHLA |
| Parker PV092 | PV092R1K1T1NHLB |
| Parker PV092 | PV092R1K1T1NHLC |
| Parker PV092 | PV092R1K1T1NHLD |
| Parker PV092 | PV092R1K1T1NKCA |
| Parker PV092 | PV092R1K1T1NKCB |
| Parker PV092 | PV092R1K1T1NKCC |
| Parker PV092 | PV092R1K1T1NKL1 |
| Parker PV092 | PV092R1K1T1NKLA |
| Parker PV092 | PV092R1K1T1NKLB |
| Parker PV092 | PV092R1K1T1NKLC |
| Parker PV092 | PV092R1K1T1NKLZ |
| Parker PV092 | PV092R1K1T1NMC1 |
| Parker PV092 | PV092R1K1T1NMCA |
| Parker PV092 | PV092R1K1T1NMCB |
| Parker PV092 | PV092R1K1T1NMCC |
| Parker PV092 | PV092R1K1T1NMF1 |
| Parker PV092 | PV092R1K1T1NMFC |
| Parker PV092 | PV092R1K1T1NMFZ |
| Parker PV092 | PV092R1K1T1NML1 |
| Parker PV092 | PV092R1K1T1NMLA |
| Parker PV092 | PV092R1K1T1NMLB |
| Parker PV092 | PV092R1K1T1NMLC |
| Parker PV092 | PV092R1K1T1NMLW |
| Parker PV092 | PV092R1K1T1NMLZ |
| Parker PV092 | PV092R1K1T1NMM1 |
| Parker PV092 | PV092R1K1T1NMMC |
| Parker PV092 | PV092R1K1T1NMMK |
| Parker PV092 | PV092R1K1T1NMMW |
| Parker PV092 | PV092R1K1T1NMMZ |
| Parker PV092 | PV092R1K1T1NMR1 |
| Parker PV092 | PV092R1K1T1NMRC |
| Parker PV092 | PV092R1K1T1NMRK |
| Parker PV092 | PV092R1K1T1NMRW |
| Parker PV092 | PV092R1K1T1NMRZ |
| Parker PV092 | PV092R1K1T1NMSC |
| Parker PV092 | PV092R1K1T1NMT1 |
| Parker PV092 | PV092R1K1T1NSCA |
| Parker PV092 | PV092R1K1T1NSCC |
| Parker PV092 | PV092R1K1T1NSCK |
| Parker PV092 | PV092R1K1T1NSCW |
| Parker PV092 | PV092R1K1T1NSL1 |
| Parker PV092 | PV092R1K1T1NSLA |
| Parker PV092 | PV092R1K1T1NSLB |
| Parker PV092 | PV092R1K1T1NSLC |
| Parker PV092 | PV092R1K1T1NSLK |
| Parker PV092 | PV092R1K1T1NSLZ |
| Parker PV092 | PV092R1K1T1NTC1 |
| Parker PV092 | PV092R1K1T1NTCA |
| Parker PV092 | PV092R1K1T1NTCC |
| Parker PV092 | PV092R1K1T1NTCZ |
| Parker PV092 | PV092R1K1T1NTL1 |
| Parker PV092 | PV092R1K1T1NTLA |
| Parker PV092 | PV092R1K1T1NTLB |
| Parker PV092 | PV092R1K1T1NTLC |
| Parker PV092 | PV092R1K1T1NTLK |
| Parker PV092 | PV092R1K1T1NTLW |
| Parker PV092 | PV092R1K1T1NTLZ |
| Parker PV092 | PV092R1K1T1NUCA |
| Parker PV092 | PV092R1K1T1NUCC |
| Parker PV092 | PV092R1K1T1NULA |
| Parker PV092 | PV092R1K1T1NULB |
| Parker PV092 | PV092R1K1T1NULC |
| Parker PV092 | PV092R1K1T1NULZ |
| Parker PV092 | PV092R1K1T1NUPD |
| Parker PV092 | PV092R1K1T1NUPE |
| Parker PV092 | PV092R1K1T1NUPF |
| Parker PV092 | PV092R1K1T1NUPG |
| Parker PV092 | PV092R1K1T1NUPK |
| Parker PV092 | PV092R1K1T1NUPM |
| Parker PV092 | PV092R1K1T1NUPP |
| Parker PV092 | PV092R1K1T1NUPR |
| Parker PV092 | PV092R1K1T1NUPS |
| Parker PV092 | PV092R1K1T1NUPT |
| Parker PV092 | PV092R1K1T1NWC1 |
| Parker PV092 | PV092R1K1T1NWCA |
| Parker PV092 | PV092R1K1T1NWCB |
| Parker PV092 | PV092R1K1T1NWCC |
| Parker PV092 | PV092R1K1T1NWL1 |
| Parker PV092 | PV092R1K1T1NWLA |
| Parker PV092 | PV092R1K1T1NWLB |
| Parker PV092 | PV092R1K1T1NWLC |
| Parker PV092 | PV092R1K1T1NWLW |
| Parker PV092 | PV092R1K1T1NWPV |
| Parker PV092 | PV092R1K1T1PFDS |
| Parker PV092 | PV092R1K1T1SUPD |
| Parker PV092 | PV092R1K1T1V001 |
| Parker PV092 | PV092R1K1T1VFDS |
| Parker PV092 | PV092R1K1T1VFFP |
| Parker PV092 | PV092R1K1T1VFHS |
| Parker PV092 | PV092R1K1T1VFPD |
| Parker PV092 | PV092R1K1T1VFPR |
| Parker PV092 | PV092R1K1T1VFPV |
| Parker PV092 | PV092R1K1T1VFRP |
| Parker PV092 | PV092R1K1T1VFTK |
| Parker PV092 | PV092R1K1T1VFWS |
| Parker PV092 | PV092R1K1T1VHLA |
| Parker PV092 | PV092R1K1T1VKLA |
| Parker PV092 | PV092R1K1T1VMM1 |
| Parker PV092 | PV092R1K1T1VMMC |
| Parker PV092 | PV092R1K1T1VMMZ |
| Parker PV092 | PV092R1K1T1VMR1 |
| Parker PV092 | PV092R1K1T1VMRC |
| Parker PV092 | PV092R1K1T1VMRZ |
| Parker PV092 | PV092R1K1T1VMTK |
| Parker PV092 | PV092R1K1T1VSL1 |
| Parker PV092 | PV092R1K1T1VSLC |
| Parker PV092 | PV092R1K1T1VUPM |
| Parker PV092 | PV092R1K1T1WFDS |
| Parker PV092 | PV092R1K1T1WFR1 |
| Parker PV092 | PV092R1K1T1WGLB |
| Parker PV092 | PV092R1K1T1WGLC |
| Parker PV092 | PV092R1K1T1WHLA |
| Parker PV092 | PV092R1K1T1WMM1 |
| Parker PV092 | PV092R1K1T1WMMC |
| Parker PV092 | PV092R1K1T1WMR1 |
| Parker PV092 | PV092R1K1T1WMRC |
| Parker PV092 | PV092R1K1T1WMRZ |
| Parker PV092 | PV092R1K1T1WUPD |
| Parker PV092 | PV092R1K1T1WUPG |
| Parker PV092 | PV092R1K1T1WUPK |
| Parker PV092 | PV092R1K1T1WUPM |
| Parker PV092 | PV092R1K1TiNMMC |
| Parker PV092 | PV092R1K4B1NWCB |
| Parker PV092 | PV092R1K4BBNML1 |
| Parker PV092 | PV092R1K4KJNUPF |
| Parker PV092 | PV092R1K4KJWMR1 |
| Parker PV092 | PV092R1K4LKNMMC |
| Parker PV092 | PV092R1K4T1N001 |
| Parker PV092 | PV092R1K4T1NFF1 |
| Parker PV092 | PV092R1K4T1NFHS |
| Parker PV092 | PV092R1K4T1NFPD |
| Parker PV092 | PV092R1K4T1NFPE |
| Parker PV092 | PV092R1K4T1NFPG |
| Parker PV092 | PV092R1K4T1NFPV |
| Parker PV092 | PV092R1K4T1NFR1 |
| Parker PV092 | PV092R1K4T1NFT2 |
| Parker PV092 | PV092R1K4T1NGCB |
| Parker PV092 | PV092R1K4T1NHLA |
| Parker PV092 | PV092R1K4T1NHLB |
| Parker PV092 | PV092R1K4T1NHLC |
| Parker PV092 | PV092R1K4T1NMF1 |
| Parker PV092 | PV092R1K4T1NMFZ |
| Parker PV092 | PV092R1K4T1NMLA |
| Parker PV092 | PV092R1K4T1NMMC |
| Parker PV092 | PV092R1K4T1NMMW |
| Parker PV092 | PV092R1K4T1NMR1 |
| Parker PV092 | PV092R1K4T1NMT1 |
| Parker PV092 | PV092R1K4T1NSCA |
| Parker PV092 | PV092R1K4T1NSLA |
| Parker PV092 | PV092R1K4T1NTCC |
| Parker PV092 | PV092R1K4T1NTLA |
| Parker PV092 | PV092R1K4T1NTLC |
| Parker PV092 | PV092R1K4T1NTLD |
| Parker PV092 | PV092R1K4T1NUCB |
| Parker PV092 | PV092R1K4T1NULA |
| Parker PV092 | PV092R1K4T1NUPD |
| Parker PV092 | PV092R1K4T1NUPE |
| Parker PV092 | PV092R1K4T1NUPF |
| Parker PV092 | PV092R1K4T1NUPG |
| Parker PV092 | PV092R1K4T1NUPM |
| Parker PV092 | PV092R1K4T1NUPP |
| Parker PV092 | PV092R1K4T1WFPD |
| Parker PV092 | PV092R1K4T1WMFB |
| Parker PV092 | PV092R1K4T1WMFC |
| Parker PV092 | PV092R1K4T1WMFK |
| Parker PV092 | PV092R1K4T1WMFW |
| Parker PV092 | PV092R1K4T1WMM1 |
| Parker PV092 | PV092R1K4T1WMMC |
| Parker PV092 | PV092R1K4T1WMMK |
| Parker PV092 | PV092R1K4T1WMMW |
| Parker PV092 | PV092R1K4T1WMR1 |
| Parker PV092 | PV092R1K4T1WUPG |
| Parker PV092 | PV092R1K4T1WUPM |
| Parker PV092 | PV092R1K8K1NFRP |
| Parker PV092 | PV092R1K8L1NFRP |
| Parker PV092 | PV092R1K8L3NFWS |
| Parker PV092 | PV092R1K8T1N001 |
| Parker PV092 | PV092R1K8T1N100 |
| Parker PV092 | PV092R1K8T1NFHS |
| Parker PV092 | PV092R1K8T1NFRP |
| Parker PV092 | PV092R1K8T1NFWS |
| Parker PV092 | PV092R1K8T1NMMC |
| Parker PV092 | PV092R1K8T1NSLC |
| Parker PV092 | PV092R1K8T1NTLC |
| Parker PV092 | PV092R1K8T1NUPG |
| Parker PV092 | PV092R1K8T1NUPZ |
| Parker PV092 | PV092R1K8T1VMMC |
| Parker PV092 | PV092R1L1K1VFTD |
| Parker PV092 | PV092R1L1KJNFPV |
| Parker PV092 | PV092R1L1L3WTCC |
| Parker PV092 | PV092R1L1T1N100 |
| Parker PV092 | PV092R1L1T1NFF1 |
| Parker PV092 | PV092R1L1T1NFFP |
| Parker PV092 | PV092R1L1T1NFHS |
| Parker PV092 | PV092R1L1T1NFPD |
| Parker PV092 | PV092R1L1T1NFPV |
| Parker PV092 | PV092R1L1T1NFRC |
| Parker PV092 | PV092R1L1T1NFRD |
| Parker PV092 | PV092R1L1T1NFRP |
| Parker PV092 | PV092R1L1T1NFT1 |
| Parker PV092 | PV092R1L1T1NFWS |
| Parker PV092 | PV092R1L1T1NGCC |
| Parker PV092 | PV092R1L1T1NGLC |
| Parker PV092 | PV092R1L1T1NHCC |
| Parker PV092 | PV092R1L1T1NKCC |
| Parker PV092 | PV092R1L1T1NKCW |
| Parker PV092 | PV092R1L1T1NKLA |
| Parker PV092 | PV092R1L1T1NMCA |
| Parker PV092 | PV092R1L1T1NMCC |
| Parker PV092 | PV092R1L1T1NMF1 |
| Parker PV092 | PV092R1L1T1NMFB |
| Parker PV092 | PV092R1L1T1NMFC |
| Parker PV092 | PV092R1L1T1NMFZ |
| Parker PV092 | PV092R1L1T1NMLA |
| Parker PV092 | PV092R1L1T1NMLZ |
| Parker PV092 | PV092R1L1T1NMM1 |
| Parker PV092 | PV092R1L1T1NMMC |
| Parker PV092 | PV092R1L1T1NMMZ |
| Parker PV092 | PV092R1L1T1NMR1 |
| Parker PV092 | PV092R1L1T1NMRC |
| Parker PV092 | PV092R1L1T1NMRZ |
| Parker PV092 | PV092R1L1T1NMTK |
| Parker PV092 | PV092R1L1T1NMTZ |
| Parker PV092 | PV092R1L1T1NSCA |
| Parker PV092 | PV092R1L1T1NSCC |
| Parker PV092 | PV092R1L1T1NSLA |
| Parker PV092 | PV092R1L1T1NSLZ |
| Parker PV092 | PV092R1L1T1NTCB |
| Parker PV092 | PV092R1L1T1NTCC |
| Parker PV092 | PV092R1L1T1NTLC |
| Parker PV092 | PV092R1L1T1NUCC |
| Parker PV092 | PV092R1L1T1NULC |
| Parker PV092 | PV092R1L1T1NUPD |
| Parker PV092 | PV092R1L1T1NUPK |
| Parker PV092 | PV092R1L1T1NUPR |
| Parker PV092 | PV092R1L1T1NUPS |
| Parker PV092 | PV092R1L1T1NWCC |
| Parker PV092 | PV092R1L1T1NWLA |
| Parker PV092 | PV092R1L1T1PKCZ |
| Parker PV092 | PV092R1L1T1VFTD |
| Parker PV092 | PV092R1L1T1VFTK |
| Parker PV092 | PV092R1L1T1VMF1 |
| Parker PV092 | PV092R1L1T1VMFZ |
| Parker PV092 | PV092R1L1T1VUCC |
| Parker PV092 | PV092R1L1T1WKCZ |
| Parker PV092 | PV092R1L1T1WTCB |
| Parker PV092 | PV092R1L1T1WTCC |
| Parker PV092 | PV092R1L4T1N001 |
| Parker PV092 | PV092R1L4T1NFPV |
| Parker PV092 | PV092R1L4T1NFR1 |
| Parker PV092 | PV092R1L4T1NKCC |
| Parker PV092 | PV092R1L4T1NMR1 |
| Parker PV092 | PV092R1L4T1NUC1 |
| Parker PV092 | PV092R1L4T1NUPE |
| Parker PV092 | PV092R1L4T1NUPG |
| Parker PV092 | PV092R1L4T1NUPP |
| Parker PV092 | PV092R1L4T1VFRC |
| Parker PV092 | PV092R1L8B1NULB |
| Parker PV092 | PV092R1L8LKNULC |
| Parker PV092 | PV092R1L8T1N001 |
| Parker PV092 | PV092R1L8T1NFRP |
| Parker PV092 | PV092R1L8T1NFWS |
| Parker PV092 | PV092R1L8T1NULC |
| Parker PV092 | PV092R2E1C1E000 |
| Parker PV092 | PV092R2E1T1E000 |
| Parker PV092 | PV092R2K1T1N001 |
| Parker PV092 | PV092R2K1T1NFWS |
| Parker PV092 | PV092R2K1T1V001 |
| Parker PV092 | PV092R9D3T1NWLA |
| Parker PV092 | PV092R9K1B1NUPG |
| Parker PV092 | PV092R9K1BBNSCC |
| Parker PV092 | PV092R9K1KJNMFC |
| Parker PV092 | PV092R9K1T1NFWS |
| Parker PV092 | PV092R9K1T1NGLC |
| Parker PV092 | PV092R9K1T1NKLC |
| Parker PV092 | PV092R9K1T1NMFB |
| Parker PV092 | PV092R9K1T1NMFC |
| Parker PV092 | PV092R9K1T1NMMC |
| Parker PV092 | PV092R9K1T1NTCC |
| Parker PV092 | PV092R9K1T1NUC1 |
| Parker PV092 | PV092R9K1T1NULW |
| Parker PV092 | PV092R9K1T1NWCC |
| Parker PV092 | PV092R9K1T1VMMW |
| Parker PV092 | PV092R9K4KJNMFC |
| Parker PV092 | PV092R9K4KJWMRC |
| Parker PV092 | PV092R9K4T1NSLB |
| Parker PV092 | PV092R9K4T1NTLB |
| Parker PV092 | PV092R9K4T1WMRC |
| Parker PV092 | PV092R9L1T1NMFC |
| Parker PV092 | PV092R9L1T1NMRZ |
| Parker PV092 | PV092R9L1T1NUCC |
| Parker PV092 | PV092R9L1T1NWCC |
Technical data
With through drive for single and multiple pumps.
Swash plate type for open circuit.
Technical Features
--Low noise level.
--Fast response.
--Service-friendly.
--High self-priming speed.
--Compact design.
--Through drive for 100% nominal torque.
| PV016 | PV020 | PV023 | PV028 | PV032 | PV040 | PV046 | ||
| Frame size | 1 | 1 | 1 | 1 | 2 | 2 | 2 | |
| Max. Displacement | [cm3/rev.] | 16 | 20 | 23 | 28 | 32 | 40 | 46 |
| Output flow at 1500 rpm | [l/min] | 24 | 30 | 34,5 | 42 | 48 | 60 | 69 |
| Nominal pressure pN | [bar] | 350 | 350 | 350 | 350 | 350 | 350 | 350 |
| Min. outlet pressure | [bar] | 15 | 15 | 15 | 15 | 15 | 15 | 15 |
| Max. pressure pmax at 20% working cycle1) | [bar] | 420 | 420 | 420 | 420 | 420 | 420 | 420 |
| drain pressure, continuous | [bar] | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 |
| drain pressure, max. peak | [bar] | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 |
| Min. Inlet pressure, abs. | [bar] | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 |
| Max. Inlet pressure | [bar] | 16 | 16 | 16 | 16 | 16 | 16 | 16 |
| Input power at 1500 rpm and 350 bar | [kW] | 15.5 | 19.5 | 22.5 | 27.5 | 31 | 39 | 45 |
| Max speed at 1 bar, abs, inlet pressure | [rpm] | 3000 | 3000 | 3000 | 3000 | 2800 | 2800 | 2800 |
| Min. speed | [rpm] | 50 | 50 | 50 | 50 | 50 | 50 | 50 |
| Moment of inertia | [kgm2] | 0.0017 | 0.0017 | 0.0017 | 0.0017 | 0.0043 | 0.0043 | 0.0043 |
| Weight | [kg] | 19 | 19 | 19 | 19 | 30 | 30 | 30 |
| PV063 | PV080 | PV092 | PV140 | PV180 | PV270 | PV360 | ||
| Frame size | 3 | 3 | 3 | 4 | 4 | 5 | 6 | |
| Max. Displacement | [cm3/rev.] | 63 | 80 | 92 | 140 | 180 | 270 | 360 |
| Output flow at 1500 rpm | [l/min] | 94.5 | 120 | 138 | 210 | 270 | 405 | 540 |
| Nominal pressure pN | [bar] | 350 | 350 | 350 | 350 | 350 | 350 | 350 |
| Min. outlet pressure | [bar] | 15 | 15 | 15 | 15 | 15 | 15 | 15 |
| Max. pressure pmax at 20% working cycle | [bar] | 420 | 420 | 420 | 420 | 420 | 420 | 420 |
| drain pressure, continuous | [bar] | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 |
| drain pressure, max. peak | [bar] | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 |
| Min. Inlet pressure, abs. | [bar] | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 |
| Max. Inlet pressure | [bar] | 16 | 16 | 16 | 16 | 16 | 16 | 16 |
| Input power at 1500 rpm and 350 bar | [kW] | 61.5 | 78 | 89.5 | 136 | 175 | 263 | 350 |
| Max speed at 1 bar, abs, inlet pressure | [rpm] | 2800 | 2500 | 2300 | 2400 | 2200 | 1800 | 1750 |
| Min. speed | [rpm] | 50 | 50 | 50 | 50 | 50 | 50 | 50 |
| Moment of inertia | [kgm] | 0.018 | 0.018 | 0.018 | 0.030 | 0.030 | 0.098 | 0.103 |
| Weight | [kg] | 59 | 59 | 59 | 90 | 90 | 172 | 180 |
PV080 Product model summary
PV080L1D3T1NWLC PV080R1E4T1NGLK PV080R1K1T1NMFZ PV080R1K4T1NMLC PV080R1D3BBNSLK PV080R1K1LKVMRZ PV080R1K1T1NULW PV080R1L1AYNGCK
PV080L1E1CDNMMC PV080R1E8T1NMMC PV080R1K1T1NML1 PV080R1K4T1NMMC PV080R1D3BBNSLK PV080R1K1T1BMFC PV080R1K1T1NULW PV080R1L1AYNGCK
PV080L1E1CDNMMC PV080R1E8T1NMMC PV080R1K1T1NMLC PV080R1K4T1NMMK PV080R1D3BBVMMC PV080R1K1T1N00045 PV080R1K1T1NWCC PV080R1L1AYNGCK
PV080L1E1T1NMF1 PV080R1K1AYNGCC PV080R1K1T1NMLC PV080R1K4T1NMMW PV080R1D3BBVMMC PV080R1K1T1N001 PV080R1K1T1VMM1 PV080R1L1AYNWCC
PV080L1E1T1NMFW PV080R1K1AYNMFW PV080R1K1T1NMLW PV080R1K4T1NMR1 PV080R1D3BBVMMC PV080R1K1T1N001 PV080R1K1T1VMM1 PV080R1L1BBNMMC
PV080L1E1T1NMM1 PV080R1K1AYNMRC PV080R1K1T1NMLW PV080R1K4T1NMR1 PV080R1D3BBVMMC PV080R1K1T1NGC1 PV080R1K1T1VMRC PV080R1L1KJNUCC
PV080L1E1T1NMM1 PV080R1K1AYNMRC PV080R1K1T1NMLW PV080R1K4T1NMRC PV080R1D3BBVMMC PV080R1K1T1NGCC PV080R1K1T1VMRC PV080R1L1KJNUCC
PV080L1E1T1NMM1 PV080R1K1BBNGCZ PV080R1K1T1NMLZ PV080R1K4T1NMRZ PV080R1D3CDNMMC PV080R1K1T1NGCC PV080R1K1T1VMRC PV080R1L1LKNMMC
PV080L1E1T1NMM1 PV080R1K1BBNGCZ PV080R1K1T1NMMC PV080R1K4T1NSCC PV080R1D3CDNMMC PV080R1K1T1NGCK PV080R1K1T1VUDM PV080R1L1LKNSCB
PV080L1E1T1NMM1 PV080R1K1BBNMF1 PV080R1K1T1NMMZ PV080R1K4T1NSL1 PV080R1D3CDNMR1 PV080R1K1T1NGCZ PV080R1K1T1WGLC PV080R1L1LKNUCC
PV080L1E1T1NMMC PV080R1K1BBNMF1 PV080R1K1T1NMR1 PV080R1K4T1NSL1 PV080R1D3CDNMRK PV080R1K1T1NGCZ PV080R1K1T1WKLC PV080R1L1T1NGL1
PV080L1E1T1NMMC PV080R1K1BBNMFB PV080R1K1T1NMRC PV080R1K4T1NSLC PV080R1D3T1NKL1 PV080R1K1T1NGLC PV080R1K1T1WMM1 PV080R1L1T1NKLC
PV080L1E1T1NMMW PV080R1K1BBNMFB PV080R1K1T1NMRC PV080R1K4T1NSLC PV080R1D3T1NKL1 PV080R1K1T1NGLC PV080R1K1T1WMMC PV080R1L1T1NKLC
PV080L1E3BBNMFC PV080R1K1BBNMLK PV080R1K1T1NMRW PV080R1K4T1NTCC PV080R1D3T1NMCC PV080R1K1T1NGLW PV080R1K1T1WMMC PV080R1L1T1NMF1
PV080L1E3CDVMFC PV080R1K1BBNMMW PV080R1K1T1NMRW PV080R1K4T1NTCC PV080R1D3T1NMCC PV080R1K1T1NGLW PV080R1K1T1WMMC PV080R1L1T1NMFC
PV080L1E3CDVMFC PV080R1K1BBNMRC PV080R1K1T1NMRZ PV080R1K4T1NUCC PV080R1D3T1NMF1 PV080R1K1T1NGLZ PV080R1K1T1WMMZ PV080R1L1T1NMLC
PV080L1E3T1NMR1 PV080R1K1BBNMRC PV080R1K1T1NMT1 PV080R1K4T1NUDM PV080R1D3T1NMF1 PV080R1K1T1NGLZ PV080R1K1T1WMRC PV080R1L1T1NMLC
PV080L1E4BBVUDR PV080R1K1BBNUDM PV080R1K1T1NMTK PV080R1K4T1NUDR PV080R1D3T1NMF1 PV080R1K1T1NHC1 PV080R1K4BBNWLZ PV080R1L1T1NMMZ
PV080L1E4BBVUDR PV080R1K1BBNUDM PV080R1K1T1NMTP PV080R1K4T1NULZ PV080R1D3T1NMF1 PV080R1K1T1NHC1 PV080R1K4BBNWLZ PV080R1L1T1NMMZ
PV080L1K1T1N100 PV080R1K1BBNUDM PV080R1K1T1NMTP PV080R1K4T1NULZ PV080R1D3T1NMF1 PV080R1K1T1NHCC PV080R1K4BBNWLZ PV080R1L1T1NMMZ
PV080L1K1T1N100 PV080R1K1BBVHCC PV080R1K1T1NSCK PV080R1K4T1VMMK PV080R1D3T1NMM1 PV080R1K1T1NHCC PV080R1K4JHNMMC PV080R1L1T1NUCC
PV080L1K1T1NMF1 PV080R1K1BCNMMC PV080R1K1T1NSCK PV080R1K4T1VUDR PV080R1D3T1NMM1 PV080R1K1T1NHCZ PV080R1K4T1N001 PV080R1L1T1NUCC
PV080L1K1T1NMLC PV080R1K1CDNWLW PV080R1K1T1NSLB PV080R1K4T1WMC1 PV080R1D3T1NMMC PV080R1K1T1NHCZ PV080R1K4T1NFDV PV080R1L1T1NWLC
PV080L1K1T1NMLC PV080R1K1CDNWLW PV080R1K1T1NSLB PV080R1K4T1WMF1 PV080R1D3T1NMMC PV080R1K1T1NHLC PV080R1K4T1NFDV PV080R1L1T1VMMZ
PV080L1K1T1NMM1 PV080R1K1CDNWLW PV080R1K1T1NSLC PV080R1K4T1WMF1 PV080R1D3T1NMMW PV080R1K1T1NHLW PV080R1K4T1NGL1 PV080R1L1T1WTCC
PV080L1K1T1NMMK PV080R1K1JHNMLC PV080R1K1T1NSLW PV080R1K4T1WMMC PV080R1D3T1NUDK PV080R1K1T1NHLW PV080R1K4T1NGL1 PV080R1L1T1WTCC
PV080L1K1T1NMRC PV080R1K1JHNMMC PV080R1K1T1NSLW PV080R1K4T1WMMC PV080R1D3T1VMF1 PV080R1K1T1NHLZ PV080R1K4T1NHL1 PV080R1L1T1WTCC
PV080L1K1T1NMRK PV080R1K1JHNMMW PV080R1K1T1NSLZ PV080R1K4T1WMMC PV080R1D3T1VMFC PV080R1K1T1NKCB PV080R1K4T1NKL1 PV080R1L4AYNSCC
PV080L1K1T1NMRK PV080R1K1JHNMR1 PV080R1K1T1NTC1 PV080R1K4T1WMMC PV080R1D3T1VMMC PV080R1K1T1NKCC PV080R1K4T1NKL1 PV080R1L4BBNMMC
PV080L1L1KJNMFC PV080R1K1JHNMRK PV080R1K1T1NTCC PV080R1K4T1WMMW PV080R1E1BBNMT1 PV080R1K1T1NKL1 PV080R1K4T1NKL1 PV080R1L4T1NHCW
PV080L1L1T1NMFC PV080R1K1JHNMRK PV080R1K1T1NTLC PV080R1K4T1WMMW PV080R1E1DFNMFC PV080R1K1T1NKL1 PV080R1K4T1NKL1 PV080R1L4T1NHCW
PV080L1L1T1NMM1 PV080R1K1KJNMFC PV080R1K1T1NTLC PV080R1K4T1WMMW PV080R1E1T1NMMC PV080R1K1T1NKLC PV080R1K4T1NKLC PV080R1L4T1NMMC
PV080L1L1T1NMM1 PV080R1K1KJNMMC PV080R1K1T1NTLW PV080R1K4T1WMMW PV080R1E1T1NUCC PV080R1K1T1NMC1 PV080R1K4T1NKLC PV080R1L4T1NMMC
PV080L1L1T1NMMC PV080R1K1KJNUDM PV080R1K1T1NUCK PV080R1K4T1WMMZ PV080R1E1T1VTCC PV080R1K1T1NMF1 PV080R1K4T1NMC1 PV080R1L4T1VMFK
PV080L1L1T1NTLC PV080R1K1LKNMFC PV080R1K1T1NUDK PV080R1K4T1WMMZ PV080R1E3CDNMFC PV080R1K1T1NMF1 PV080R1K4T1NMC1 PV080R1L4T1VMMC
PV080R1D1T1NFDV PV080R1K1LKNMMC PV080R1K1T1NUDK PV080R1K8T1NMMC PV080R1E3CDNMFC PV080R1K1T1NMF1 PV080R1K4T1NMC1 PV080R1L4T1VMMC
PV080R1D1T1NFDV PV080R1K1LKNMRC PV080R1K1T1NUDM PV080R1K8T1NMMC PV080R1E3CDNMFC PV080R1K1T1NMFB PV080R1K4T1NMC1 PV080R2K1T1N001
PV080R1D3AYNMM1 PV080R1K1LKNMRC PV080R1K1T1NUDM PV080R1L1AYNGCK PV080R1E3T1VMFC PV080R1K1T1NMFB PV080R1K4T1NMFB PV080R2K1T1N001
PV080R1D3AYNMRC PV080R1K1LKNMRZ PV080R1K1T1NULC PV080R1L1AYNGCK PV080R1E4T1NGLK PV080R1K1T1NMFB PV080R1K4T1NMFZ PV080R2K4LKN001
PV080R2L4T1WMMW PV080R2L4T1WMMW PV080R2K4LKN001
Video
